SOCAY Low Leakage Current SOT23-3L Package 36V SE36T2R02GY Transient Voltage Suppressors For ESD Protection
SKU: SE36T2R02GY
(0)
0 Sold
$0.04
$0.05
The Price Is For Reference Only. Please Consult Customer Service.
Part Number：SE36T2R02GY
Peak Reverse Working Voltage—Vrwm(V)：36.0
Reverse Leakage Current —IR Max(μA)：1.0
Breakdown Voltage @ IT—IT=1mA VBR Min(V)：40.0
Clamping Voltage @ Ipp—Ipp=1A , tp=8/20μs Vc (V)：50.0
Clamping Voltage @ Ipp—Ipp=5A , tp=8/20μs Vc (V)：60.0
Junction Capacitance @ VR=0V,f=1MHz—CJ(pF)：9.0
Part Number：SE36T2R02GY
Peak Reverse Working Voltage—Vrwm(V)：36.0
Reverse Leakage Current —IR Max(μA)：1.0
Breakdown Voltage @ IT—IT=1mA VBR Min(V)：40.0
Clamping Voltage @ Ipp—Ipp=1A , tp=8/20μs Vc (V)：50.0
Clamping Voltage @ Ipp—Ipp=5A , tp=8/20μs Vc (V)：60.0
Junction Capacitance @ VR=0V,f=1MHz—CJ(pF)：9.0
