SOCAY Official Varistor Plugins Manufacturer 14D Series MOV 14D331KJ Voltage V1mA 297V to 363V for Surge Protection
(0)
0 Sold
$0.04
$0.14
The Price Is For Reference Only. Please Consult Customer Service.
Type Number: 14D331K
Maximum Allowable voltage Vac(V)：210
Varistor Voltage Vdc(V)：275
Varistor Voltage V1mA(V): 330(297~363)
Maximum Clamping Voltage Ip(A): 50
Maximum Clamping Voltage Vc(V): 550
Withstanding Surge Current I(A) (1 time): 6000
Withstanding Surge Current I(A) (2 times): 5000
Maximum Energy(10/1000μs) (J): 115.0
Rated Power(W): 0.6
Typical Capacitance (Reference) @1KHZ (pf): 610
Type Number: 14D331K
Maximum Allowable voltage Vac(V)：210
Varistor Voltage Vdc(V)：275
Varistor Voltage V1mA(V): 330(297~363)
Maximum Clamping Voltage Ip(A): 50
Maximum Clamping Voltage Vc(V): 550
Withstanding Surge Current I(A) (1 time): 6000
Withstanding Surge Current I(A) (2 times): 5000
Maximum Energy(10/1000μs) (J): 115.0
Rated Power(W): 0.6
Typical Capacitance (Reference) @1KHZ (pf): 610
